Hoymiles HAT-6.0HV-EUG1 3-phase inverter

The Hoymiles HAT-6.0HV-EUG1 is a three-phase AC-coupled inverter with a rated power of 6000 W designed for upgrading existing PV installations. It allows operation in self-consumption, economic, and backup modes, supporting integration with Li-ion batteries and operation in a system with other inverters (up to 10 in parallel).

Manufacturer: Hoymiles Power Electronics Inc. is a company specializing in microinverter solutions and energy storage systems. The HAT-6.0HV-EUG1 model comes from the HAT-HV-EUG1 series designed for AC coupling with existing PV installations and remote monitoring via the S-Miles Cloud platform.

Electrical parameters

• Output power (rated): 6000 W
• Max. apparent output power: 6600 VA
• Max. input power: 12000 W
• Battery voltage range: 170–600 V
• Max. charging/discharging current: 20 A / 20 A
• Max. charging/discharging power: 6000 W / 6000 W
• Communication with BMS: CAN
• Grid / output voltage: 3L/N/PE, 380/400 V (range 266–480 V)
• Rated frequency: 50/60 Hz
• Max. output current: 10.0 A (continuous)
• Power factor: >0.99 (adjustable 0.8 leading … 0.8 lagging)
• THDi (@ rated power): < 3%
• Max. efficiency: 97.5%

Mechanical and environmental parameters

• Dimensions (W × H × D): 502 × 486 × 202 mm
• Weight: 23 kg
• Mounting: wall-mounted
• Operating temperature range: -25 to +65 °C (at >45 °C power derating required)
• Relative humidity: 0–95%, non-condensing
• Cooling: natural convection
• Protection class: IP65
• Noise level: < 40 dB
• Topology (battery): transformerless
• Max. altitude: ≤ 2000 m
• User interface: LED, app
• Digital I/O: DRM, 1 × DI, 2 × DO
• Additional communication: RS485; optionally Wi‑Fi / Ethernet / 4G (DTS-4G coming soon)
