LONGi 655W Hi-MO X10 Mono Silver photovoltaic panel
The LONGi Hi-MO X10 Scientist 655W photovoltaic module is a modern high-efficiency monocrystalline panel using TaiRay wafer technology and BC (Back Contact) cells, which ensure excellent reliability, lower operating temperature and long-term power stability. Thanks to optimised manufacturing process and strict quality testing, the panel guarantees maximum efficiency and durability throughout the 30-year service life.
Shipping costs are not included in the price.
Shipping costs are not included in the price.
Ask about the product
Administratorem danych osobowych jest Master Investment sp. z o.o.. Przetwarzamy je w celu przesłania odpowiedzi na zapytanie. Więcej informacji dotyczących przetwarzania danych osobowych znajduje się w polityce prywatności.
Product code: ME5256
Cechy produktu
Panel parameters
- Panel power 650-700 W
- Cell type Back Contact
- Frame colour Silver
- Sales unit Single unit
- Module height over 200 cm
- Panel power [W] 655
- Module height [cm] 238.2
Opis
The LONGi Hi-MO X10 Scientist 655W photovoltaic module is a modern high-efficiency monocrystalline panel using TaiRay wafer technology and BC (Back Contact) cells, which ensure excellent reliability, lower operating temperature and long-term power stability. Thanks to production process optimisation and rigorous quality testing, the panel guarantees maximum efficiency and durability over the entire 30-year operational period.
LONGi is a global leader in photovoltaic component manufacturing, specialising in monocrystalline cells and modules. The company is known for innovative technologies, high quality standards and a sustainable approach to renewable energy production.
Electrical parameters
- Maximum power (Pmax): 655 W
- Open-circuit voltage (Voc): 54.00 V
- Short-circuit current (Isc): 15.37 A
- Voltage at maximum power point (Vmp): 44.66 V
- Current at maximum power point (Imp): 14.67 A
- Module efficiency: 24.2%
- Power tolerance: 0 ~ +3%
- Is temperature coefficient: +0.050%/°C
- Voc temperature coefficient: -0.200%/°C
- Pmax temperature coefficient: -0.260%/°C
Mechanical parameters
- Dimensions: 2382 × 1134 × 30 mm
- Weight: 28.5 kg
- Cell layout: 144 (6×24)
- Glass: single, 3.2 mm tempered with anti-reflective coating
- Frame: anodised aluminium in silver colour
- Connectors: EVO2, IP68 protection class, three bypass diodes
- Cable length: 1400 mm (+400, -200 mm)
- Maximum load (front/rear): 5400 Pa / 2400 Pa
- Operating temperature: -40°C ~ +85°C
- Fire safety rating: IEC Class C
