Description
The V20-C 3-PH-1000 surge protector is a three-pole device designed to protect photovoltaic installations from DC surges. The device includes a plug-in varistor with a disconnect unit, offers low DC protection level, and a visual status indicator for installation in distribution cabinets.
Manufacturer: OBO Bettermann – the product comes from a manufacturer specialized in surge protection and installation solutions. In the manufacturer's documentation, full electrical and mechanical parameters and certifications compliant with EN/IEC standards are provided in the technical data sheet.
Electrical Parameters
- Maximum Continuous DC Voltage: 1000 V
- Nominal Discharge Current (In, 8/20 µs): 20 kA
- Maximum Discharge Current (Imax, 8/20 µs): 40 kA
- Protection Level (Up): ≤ 4.0 kV
- Class / Type according to SPD: Type 2 (Test class, type 2)
- Response Time: < 25 ns
- DC Network / Network Form: dedicated for photovoltaic installations (PV)
- Maximum Wire Cross-Section: 35 mm² (rigid)
- Minimum Wire Cross-Section: 2.5 mm² (rigid)
- Disconnection Protection (Blow-out): no
Mechanical and Environmental Parameters
- Number of Poles / Field Version: 3 (three-pole for PV systems)
- Construction Width: 3 division units (3 × 17.5 mm = 52.5 mm)
- Mounting: DIN rail 35 mm
- Protection Class: IP20
- Status Indication: visual (on the device)
- Operating Temperature Range: from -40 °C to +80 °C
- Number of Wires (without protective wire): 2
- Maximum Permissible Overcurrent Protection on the Network Side (back-up): 125 A (maximum fuse/protection 125 A)
- Weight (in technical data sheet): 34.519 kg (value provided in unit: kg/100 pcs.)
